7” HD Monitor
| Model | Features | Specifications | Picture | Unit Price ( USD ) | |||
| KY7060HD | • Peaking Focus Assist (1. Red highlight over parts of the image in focus; 2. Red highlight over parts of the monochrome image in focus) • Exposure (Zebra) • Brightness Histogram • False Colors • Camera 5D II Mode • Check Field (Red, Green, Blue, Mono) • Pixel to Pixel • Center Marker • Safe Marker (80%, 85%, 90%, 93%, 96%,2.35:1) • Image Flip (Horizontal, Vertical, Hor&Ver) • Image Freeze |
Screen size: | 7'' |      |
|||
| Resolution: | 1280*800 Pixels | ||||||
| Dot pitch: | 0.117*0.117mm | ||||||
| Aspect ratio: | 16:9 | ||||||
| Brightness: | 400cd/m² | ||||||
| Contrast: | 800:1 | ||||||
| Backlight: | LED | ||||||
| Response Time: | 15ms | ||||||
| Viewing Angle: | 89°/89°(L/R) 89°/89°(U/D) | ||||||
| Inputs: | 3G/HD/SD-SDI HDMI Ypbpr Video Audio | ||||||
| Outputs: | 3G/HD/SD-SDI HDMI Ypbpr Video Stereo Headphone Speaker (built-in) |
||||||
| SDI Support Mode: | 480i/576i | ||||||
| 720p (60/59.94/50/30/29/25/24/23.98) | |||||||
| 1080i (60/59.94/50) | |||||||
| 1080p (60/59.94/50/30/29.97/25/24/24fps/23.98/23.98fps) | |||||||
| HDMI Support Mode: | 480i/576i/480p/576p | ||||||
| 720p (60/59.94/50/30/29/25/24/23.98) | |||||||
| 1080i (60/59.94/50) | |||||||
| 1080p (60/59.94/50/30/29.97/25/24/24fps/23.98/23.98fps) | |||||||
| Power Consumption: | ≤12W | ||||||
| Input Voltage: | DC 6-18V | ||||||
| working Temperature: | -10℃~55℃ | ||||||
| storage Temperature: | -20℃~65℃ | ||||||
| Install Way: | 1/4"-20 Thread Socket (All 4 Sides) | ||||||
| Unit Size: | 210 L ×160 W ×62 H (mm) | ||||||
| Unit Weight: | 780g ± 20g | ||||||
